Setting Up the PC Controller Program • 40
Cylinders Window
The Cylinders Window allows you to keep track of cylinders that are in use and the
expiration date for those cylinders. If a cylinder’s expiration date has passed, the PC
Controller program will alert you in the message area of the main program window as
soon as the program is started. The Cylinders window comes with a list of predefined
cylinders that are fairly common. If a cylinder that you need to use is not on this list, it
can be added at the bottom of the cylinder list. You may add as many custom
cylinders as necessary.
Figure 28: Cylinders Window
The Cylinders window has the cylinder list number, the cylinder name, the part
number, the expiration date, and the status of the cylinder.
Selecting a Cylinder from the Predefined List
The Cylinders Window comes with several predefined cylinders that you can choose
from.
1.
To access the Cylinders Window, click the Cylinders button along the top of the
main program window.
