RKI Instruments SDM-2012 PC Controlled Configuration User Manual
Page 12
7 • Description
A check valve is included with the SDM-2012. It is intended for use on the exhaust
fitting when manifolding multiple docking stations together. See “Assembling a
Manifold for Multiple SDM-2012 Units” on page 15 for manifolding instructions.
Three T-fittings are included with the SDM-2012. The larger fitting is for the exhaust
tubing manifold construction. The two smaller fittings are for GAS 1 and GAS 2 tubing
manifold construction.
Figure 5: Check Valve
For Exhaust
Tubing
For GAS
Tubing
Figure 6: T-Fittings
