SWIFT 20 Sensors 74
Test Track Vehicle for Slip Ring Sensor
Installing the Transducer
Test Track Vehicle for Slip Ring Sensor
Equipment required
This procedure requires one person. To install the SWIFT 20A or SWIFT 20T
slip ring sensor, you will need the following equipment:
• Hub adapter (see next figure)
• Modified rim (see next figure)
• Anti-rotate assembly (including customer-supplied mounting arm)
• Small set of hex-head wrenches (both English and metric)
• Tube bender for the anti-rotate bar
• Tube cutter
• Metric socket head drive set (up to 14 mm) with extension
• 5/16-18 UNC tap
• Molykote g-n paste (MTS part number 011-010-207)
• Bolts
For SWIFT 20A Transducer
40 size M8 X 1.25 mm
8 size M5 X 0.8 mm
lug nuts
For SWIFT 20T Transducer
32 size M10 X 1.5 mm
12 size M8 X 1.25 mm
8 size M5 X 0.8 mm
Lug nuts
• Torque wrenches, capable of the following ranges:
14–28 N•m (10–20 lbf•ft);
28–54 N•m (20–40 lbf•ft),
81–136 N•m (60-100 lbf•ft);
7 N•m (60 lbf •in)
• Cables (transducer and BNC, plus customer-supplied from transducer
interface to data recorder). If the SWIFT is designed to operate with the
Low-Profile TI and you have a Mini TI, you will need an adapter cable,
MTS part number 100224052.
• Tie wraps
• Data recorder
