Specifications

SWIFT 20 Sensors

Hardware Overview

27

Power Requirements

Input voltage

Supply current

Fuse

10–17 V DC

2 A typical, 3 A maximum at 12 V DC

3 A fast-blow

Angular velocity

Encoder limit

Processing limit

Encoder resolution

2,200 rpm maximum

10,000 rpm maximum

2048 counts per revolution
(512 pulses with quadrature)

Time delay (encoder tick to main output stable)

12 µs (typical)

Transducer cable length

100 ft maximum

Shunt cable length

100 ft maximum

Analog outputs

Voltage

Capacitive load

Current

Noise at output, with typical gains

±10 V range

(force and moment outputs)

0–5 V sawtooth (angle output)

0.01 µF maximum

6 mA maximum

7 mVpp, DC - 500 Hz (typical)
15 mVpp, DC - 500 Hz (maximum)

Bandwidth (bridge input to main output)

–3 dB at 30.1 kHz (typical)
90 degree at 16.6 kHz (typical)

*

Add 25.4 mm (1.0 in) for ground lugs.

† Standard from MTS. Other full scale voltages can be evaluated and may be provided at special

request.

Low-Profile Transducer Interface Communications (part 1 of 2)

Parameter

Specification

Communications Channel # 1
(Remote Host Connections)

Baud rates

Parity

Stop bits

Data bits

Isolated RS-232/RS-485 interface power
supply

Electrical interface

Maximum number of devices that can be part
of a RS-485 multidrop chain

19,200 Kbits/s

None

1

8

+5 V DC @ 200 mA maximum

Isolated RS-232 or RS-485 remote host connection
Isolated RS-485 TI to TI connection

32 with RS-232 remote host

*

31 with RS-485 remote host

Maximum cable length

Low-Profile Transducer Interface (part 2 of 2)

Parameter

Specification
