Bolt torque sequence – MTS SWIFT 20 Ultra Sensor User Manual
Page 103

Road Simulator
SWIFT 20 Sensors
Installing the Transducer
103
Note
To minimize negative clamping effects, you must torque the bolts in the
sequence shown.
Bolt Torque Sequence
SWIFT 20T
Viewed from Pilot Side
Rim Pilot
Tabs (8)
SWIFT 20A
Viewed from Pilot Side
Rim Pilot
Tabs (8)
S20-16
1
2
3
4
5
6
7
8
9
16
19
1014
18
15
12
13
17
20
11
1
2
3
4
5
6
7
8
9
16
19
10
14
18
15
12
13
17
20
11
1
2
3
5
6
7
8
9
16
19
10
14
18
15
12
13
17
20
11
21
24
23
22
4
1
2
3
5
6
7
8
16
19
10
14
18
15
12
13
17
20
11
4
9
Inner Bolt Pattern
All bolts are M8
Outer Bolt Pattern
All bolts are M8
Inner Bolt Pattern
Bolts 14 are M8.
Bolts 520 are M10
Outer Bolt Pattern
Bolts 18 are M8.
Bolts 924 are M10
