MTS SWIFT 20 Ultra Sensor User Manual
Page 28
SWIFT 20 Sensors
28
Specifications
Hardware Overview
For RS-232 host:
50 ft from host to the first (nearest) TI,
and
300 ft from the first TI to the last SWIFT TI in the RS-
485 multidrop chain
For RS-485 host:
300 ft from host to the last (furthest) TI in the RS-485
multidrop chain
*
Includes all compatible devices, such as an MTS 407 controller. A maximum of only nine transducer
interfaces can be connected, because the addresses are limited to 1–9.
Low-Profile Transducer Interface Communications (part 2 of 2)
Parameter
Specification
