SWIFT 20 Sensors 26
Specifications
Hardware Overview
Transducer Center-of-Gravity
Transducer Center-of-Gravity and Inertia Specifications
Material
Aluminum Titanium
X
cg
0.0 mm 0.000 in 0.0 mm 0.000 in
Y
cg
19.2 mm 0.755 in 19.2 mm 0.755 in
Z
cg
0.0 mm 0.000 in 0.0 mm 0.000 in
I
xx 180 kg·cm
2
62 lbm·in
2
290 kg·cm
2
99 lbm·in
2
I
yy 353 kg·cm 2 121 lbm·in 2 569 kg·cm 2 195 lbm·in 2
I
zz 180 kg·cm
2
62 lbm·in
2
290 kg·cm
2
99 lbm·in
2
Low-Profile Transducer Interface (part 1 of 2)
Parameter Specification
Physical
Height
Width
Depth
Weight
Rack Mounting Kit
31.75 mm (1.25 in)
431.8 mm (17 in)
215.9 mm (8.5 in.)
*
1.68 kg (3 lb 11.1 oz)
Optional
Environmental
Ambient temperature
Relative humidity
0° C (32° F) to 50° C (122° F)
0 to 85%, non-condensing
