Lenze EVF9333−xV - Manual (Page 401)

Configuration
Code table
8
8.5
l
8.5−53 EDSVF9333V EN 4.0−11/2007
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0830
s
^ Selection list 2 Configuration of digital input
signals, function block OR1 See System
Manual
(extension)
1 CFG: IN 1000 FIXED0 OR1−IN1
2 CFG: IN 1000 FIXED0 OR1−IN2
3 CFG: IN 1000 FIXED0 OR1−IN3
C0831 0 1 Function block OR1
l Display of the signals linked in
C0830
1 DIS: IN OR1−IN1
2 DIS: IN OR1−IN2
3 DIS: IN OR1−IN3
C0832
s
^ Selection list 2 Configuration of digital input
signals, function block OR2 See System
Manual
(extension)
1 CFG: IN 1000 FIXED0 OR2−IN1
2 CFG: IN 1000 FIXED0 OR2−IN2
3 CFG: IN 1000 FIXED0 OR2−IN3
C0833 0 1 Function block OR2
l Display of the signals linked in
C0832
1 DIS: IN OR2−IN1
2 DIS: IN OR2−IN2
3 DIS: IN OR2−IN3
C0834
s
^ Selection list 2 Configuration of digital input
signals, function block OR3 See System
Manual
(extension)
1 CFG: IN 1000 FIXED0 OR3−IN1
2 CFG: IN 1000 FIXED0 OR3−IN2
3 CFG: IN 1000 FIXED0 OR3−IN3
C0835 0 1 Function block OR3
l Display of the signals linked in
C0834
1 DIS: IN OR3−IN1
2 DIS: IN OR3−IN2
3 DIS: IN OR3−IN3
C0836
s
^ Selection list 2 Configuration of digital input
signals, function block OR4 See System
Manual
(extension)
1 CFG: IN 1000 FIXED0 OR4−IN1
2 CFG: IN 1000 FIXED0 OR4−IN2
3 CFG: IN 1000 FIXED0 OR4−IN3
C0837 0 1 Function block OR4
l Display of the signals linked in
C0836
1 DIS: IN OR4−IN1
2 DIS: IN OR4−IN2
3 DIS: IN OR4−IN3
