Configuration
Function blocks
Internal motor control with vector control (MCTRL2)
8
8.2
8.2.7
l
8.2−57 EDSVF9333V EN 6.2−04/2012
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0901
s
CFG: I−SET 1000 FIXED0% ^ Selection list 1 Configuration of analog input
signal, function block MCTRL
l Setting of integral action
component of the speed
controller
^
8.2−48
C0902
s
CFG: I−LOAD 1000 FIXED0 ^ Selection list 2 Configuration of digital input
signal, function block MCTRL
l HIGH = the integral action
component at MCTRL−I−SET is
accepted by the speed
controller
C0904
s
CFG: DC−BREAK 1000 FIXED0 ^ Selection list 2 Configuration of digital input
signal, function block MCTRL
l HIGH = Motor is braked
^
8.2−25
^
8.2−48
C0905 DIS: DC−BREAK 0 1 Function block MCTRL
l Display of the signal linked in
C0904
C0906 −199.99 {0.01 %} 199.99 Function block MCTRL
l Display of the signals linked in
C0890, C0891, C0892, C0893,
C0901 and C0903
^
8.2−25
^
8.2−48
1 DIS: N−SET
2 DIS: M−ADD
3 DIS: LO−M−LIM
4 DIS: HI−M−LIM
5 DIS: I−SET
6 DIS: BOOST
C0907 0 1 Function block MCTRL
l Display of the signals linked in
C0899, C0900 and C0902
1 reserved
2 DIS: N/M−SWT
3 DIS: QSP
4 DIS: I−LOAD
C0909 speed limit 1 1 +/− 175 % Speed limitation, function block
MCTRL
l Limitation of direction of
rotation for the speed setpoint
^
8.2−25
^
8.2−48
2 0 ... 175 %
3 −175 ... 0 %
C0910
s
CFG: VP−ADAPT 1006 FIXED100% ^ Selection list 1 Configuration of analog input
signal, function block MCTRL
l Gain adaptation of the speed
controller
l If the gain is varying, join to
CURVE−OUT of FB CURVE
^
8.2−25
^
8.2−48
C0911 DIS: VP−ADAPT −199.99 {0.01 %} 199.99 Function block MCTRL
l Display of the signal linked in
C0910
C0912 OV delay time à − {1 ms} − Delay time of the pulse enable
after an OU message
à Depending on C0082, C0086,
C0087, C0088, C0089, C0090,
C0091, C0092
A change of one of the codes
resets C0912 to the time of the
selected motor
l The time is derived from the
double rotor time constant
^
8.2−25
^
8.2−48
^ 9.4−3
