Configuration
Code table
8.5
l
8.5−39
EDSVF9333V EN 4.0−11/2007
IMPORTANT
Possible settings
Code
Selection
Lenze
Name
No.
C0630 Max limit
100.0
0
−199.99
{0.01 %}
199.99 Upper limit, function block LIM1
l
The analog input signal is
limited to the set value
See System
Manual
(extension)
C0631 MiN limit
−100.0 −199.99
{0.01 %}
199.99 Lower limit, function block LIM1
l
The analog input signal is
limited to the set value
C0632
s
CFG: IN
1000 FIXED0%
^ Selection list 1
Configuration of analog input
signal, function block LIM1
C0633 DIS: IN
−199.99
{0.01 %}
199.99 Function block LIM1
l
Display of the signal linked in
C0632
C0640 Delay T
20.00 0.01
{0.01 s}
50.00 Time constant, function block
PT1−1
l
Time period by which the
output of analog signal is
delayed
See System
Manual
(extension)
C0641
s
CFG: IN
1000 FIXED0%
^ Selection list 1
Configuration of analog input
signal, function block PT1−1
C0642 DIS: IN
−199.99
{0.01 %}
199.99 Function block PT1−1
l
Display of the signal linked in
C0641
C0643 Delay T
20.00 0.01
{0.01 s}
50.00 Time constant, function block
PT1−2
l
Time period by which the
output of analog signal is
delayed
C0644
s
CFG: IN
1000 FIXED0%
^ Selection list 1
Configuration of analog input
signal, function block PT1−2
C0645 DIS: IN
−199.99
{0.01 %}
199.99 Function block PT1−2
l
Display of the signal linked in
C0644
C0650 DT1−1 gain
1.00
−320.00
{0.01 }
320.00 Gain, function block DT1−1
l
Gain of the analog input signal
See System
Manual
(extension)
C0651 Delay T
1.000 0.005
{0.01 s}
5.000 Time constant, function block
DT1−1
l
Time period by which the
output of analog signal is
delayed
C0652
s
CFG: IN
1000 FIXED0%
^ Selection list 1
Configuration of analog input
signal, function block DT1−1
C0653 Sensibility
1
1
15 bits
Input sensitivity, function block
DT1−1
l
According to the setting only
the indicated higher−order bits
are evaluated
2
14 bits
3
13 bits
4
12 bits
5
11 bits
6
10 bits
7
9 bits
C0654 DIS: IN
−199.99
{0.01 %}
199.99 Function block DT1−1
l
Display of the signal linked in
C0652
