Configuration
Function blocks
Internal motor control with vector control (MCTRL2)
8
8.2
8.2.7
l
8.2−55 EDSVF9333V EN 6.2−04/2012
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0143 limit 2 kHz 0.0 0.0 {0.1 Hz} 20.0 Speed−dependent switching
threshold
l Threshold for automatic
switching frequency reduction
l The controller changes
automatically to 2 kHz when
this value falls below the
threshold
^
8.2−25
^
8.2−48
C0145
s
select ref 1 Selection of the flying restart
mode
l Reference speed with which
the flying restart process is
started
^
8.2−36
^
8.2−65
0 REF: C0011 Maximum speed
1 REF: N−ACT Last current speed
2 REF: N−SET Defined main speed setpoint
It is referenced to the setpoint
signal at input NSET−N of the
function block NSET.
If the setpoint signal at input
NSET−N is missing, it is referenced
to the active JOG setpoint
(C0039/x)
C0146 fly current 0 −500 {1} 500 Flying restart circuit, quantity of
current during search process
l Influences the current injection
during search process
l ±500 » ±39 % of I
max
l The initial value amounts to
» 8 % of I
max
^
8.2−36
^
8.2−65
C0147 fly dt−f 0 −82 {1} 82 Flying restart circuit, search speed
during flying restart process
l For drives with great
centrifugal masses, reduce the
search speed, if required
l ±82 ¢ ±5.0 Hz
C0148
s
ident run 0 0 WRK
stop Ready Motor data identification
1. Inhibit controller, wait until
drive has stopped
2. Enter the correct values of the
motor nameplate into C0087,
C0088, C0089, C0090, C0091
3. Set C0148 = 1, confirm with
v
4. Enable controller
The identification
– starts,
c goes off. The
motor "whistles" but does
not rotate!
– lasts approx. 1 ... 2 min
– is completed when
c is lit
again
5. Inhibit controller:
^
6.6−14
1 WRK run Start identification
C0234 damp value 20 −100 {1 %} 100 Influence of the oscillation
damping, function block MCTRL
l Minimising a tendency to
oscillation of the drive
l Influences the tendency to
oscillation of the drive
l When C0025 >1 and C0006 = 1,
C0234 is set to 0
^
8.2−25
^
8.2−48
