Configuration
Function blocks
Diameter calculator (DCALC)
8
8.2
8.2.1
l
8.2−2 EDSVF9333V EN 6.2−04/2012
IMPORTANT Possible settings Code
Selection Lenze Name No.
C1309
s
Dmin 50 1 {1 mm} 10000 Minimum diameter, function
block DCALC1
^
8.2−1
C1310 DCALC1−Titime 0.000 0.000 {0.001 s} 999.900 Acceleration and deceleration
time, function block DCALC1
C1311 window D−calc 1.00 0.00 {0.01 %} 100.00 Window − diameter calculation,
function block DCALC1
l Window setting for permissible
diameter deviation
C1320
s
CFG: SET 1000 FIXED0% ^ Selection list 1 Configuration of analog input
signal, function block DCALC1
l The signal is scaled to the value
in C1304
(100 %
¢ C1304)
^
8.2−1
C1321
s
^ Selection list 2 Configuration of digital input
signals, function block DCALC1
1 CFG: LOAD 1000 FIXED0 l HIGH: initial value at
DCALC1−SET is accepted
l DCALC1−LOAD has a higher
priority than DCALC1−HOLD
2 CFG: HOLD 1000 FIXED0 l HIGH = holds the diameter
value reached and resets the
integrators.
C1322 −36000 {1 rpm} 36000 Function block DCALC1
l Display of the signals linked in
C1327
^
8.2−1
1 DIS: N−Line
2 DIS: N−WIND
C1325 DIS: SET −199,99 {0.01 %} 199,99 Function block DCALC1
l Display of the signal linked in
C1320
C1326 0 1 Function block DCALC1
l Display of the signals linked in
C1321
1 DIS: LOAD
2 DIS: HOLD
C1327
s
^ Selection list 3 Configuration of input signals,
function block DCALC1
^
8.2−1
1 CFG: N−Line 1000 FIXED0INC l Speed signal of the line drive
2 CFG: N−WIND 1000 FIXED0INC l Speed signal of the winding
drive
C1328 DIS: D−ACT −200 {1 mm} 200 Function block DCALC1
l Display of the current diameter
The signal at DCALC1−Set is set as initial value.
ƒ With DCALC1−LOAD = 1 the initial value is accepted.
ƒ The initial value is accepted unfiltered.
Setting the initial value
