Wiring of the standard device
Notes on project planning
Mains choke/mains filter assignment
5
5.2
5.2.9
l
5.2−8 EDSVF9333V EN 6.2−04/2012
5.2.9 Mains choke/mains filter assignment
Operation with rated power (normal operation)
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9321−xV EZN3A2400H002 EZN3A2400H002 5 EZN3B2400H002 50
EVF9322−xV EZN3A1500H003 EZN3A1500H003 5 EZN3B1500H003 50
EVF9323−xV EZN3A0900H004 EZN3A0900H004 5 EZN3B0900H004 50
EVF9324−xV EZN3A0500H007 EZN3A0500H007 5 EZN3B0500H007 50
EVF9325−xV EZN3A0300H013 EZN3A0300H013 5 EZN3B0300H013 50
EVF9326−xV ELN3−0150H024−001 EZN3A0150H024 5 EZN3B0150H024 50
EVF9327−xV ELN3−0088H035−001 EZN3A0110H030 25 E82ZN22334B230 10
E82ZZ15334B230 1) 10
E82ZN22334B230 50 EZN3B0110H030U 2) 50
E82ZZ15334B230 1) 50
EVF9328−xV ELN3−0075H045 EZN3A0080H042 25 E82ZN22334B230 10
E82ZN22334B230 50 EZN3B0080H042 50
EVF9329−xV ELN3−0055H055 EZN3A0055H060 25 E82ZN30334B230 10
E82ZN30334B230 50 EZN3B0055H060 50
EVF9330−xV ELN3−0038H085 EZN3A0037H090 25 E82ZN45334B230 10
E82ZN45334B230 50 EZN3B0037H090 50
EVF9331−xV ELN3−0027H105−001 EZN3A0030H110 25 E82ZN55334B230 10
EZN3A0030H110N001 3) 25
E82ZN55334B230 50 EZN3B0030H110 50
EVF9332−xV ELN3−0022H130 EZN3A0022H150 25 E82ZN75334B230 10
E82ZN75334B230 50 EZN3B0022H150 50
EVF9333−xV ELN3−0017H170 EZN3A0017H200 25 E82ZN90334B230 10
E82ZN90334B230 50 EZN3B0017H200 50
1) RFI filter
2) Footprint filter
3) For controllers with thermal separation
