Technical data
Operation with rated power (normal operation)
Rated data for 480 V mains voltage
3.4
3.4.2
l
3.4−3
EDSVF9333V EN 6.2−04/2012
3.4.2
Rated data for 480 V mains voltage
Basis of the data
Voltage
Frequency
AC mains connection
[U
N
]
3/PE AC 384 V − 0 % ... 528 V + 0 %
45 Hz − 0 % ... 65 Hz + 0 %
DC−mains connection
(alternatively)
[U
DC
]
DC 540 V − 0 % ... 740 V + 0 %
˘
Output voltage
With mains choke
3 ~ 0 approx. 94 % V
rated
˘
Without mains choke
3 ~ 0 ... U
N
˘
9300
Mains current
1)
Typical motor power
Output power
Power loss
With
Mains choke
Without
Mains choke
ASM
(4−pole)
2/4 kHz
2)
8 kHz
2)
U, V, W
U, V, W
+U
G
, −U
G
3)
Type
I
r
[A]
I
r
[A]
P
rated
[kW]
P
rated
[hp]
S
rated
[kVA]
S
rated
[kVA]
P
DC
[kW]
P
loss
[W]
EVF9321−xV
1.5
2.1
0.37
0.5
1.2
1.2
2.3
50
EVF9322−xV
2.5
3.5
0.75
1.0
2.1
2.1
0.9
65
EVF9323−xV
3.9
5.5
1.5
2.0
3.2
3.2
0
100
EVF9324−xV
7.0
˘
3.0
4.0
5.8
5.8
2.5
150
EVF9325−xV
12.0
16.8
5.5
7.5
10.8
10.8
0
210
EVF9326−xV
20.5
˘
11.0
15.0
18.5
18.5
0
390
EVF9327−xV
29.0
43.5
18.5
25.0
26.6
26.6
11.8
430
EVF9328−xV
42.0
˘
30.0
40.0
39.1
39.1
4.6
640
EVF9329−xV
55.0
˘
37.0
50.0
49.9
49.9
0
810
EVF9330−xV
80.0
˘
55.0
75.0
69.8
69.8
5.9
1100
EVF9331−xV
100
˘
75.0
100
91.4
91.4
0
1470
EVF9332−xV
135
˘
90.0
125
124
124
32.4
1960
EVF9333−xV
165
˘
110.0
150
158.2
149
47.1
2400
1)
Mains currents at a switching frequency of 8 kHz
2)
Switching frequency of the inverter
3)
Power supplied by the DC bus when operating with power−adapted motor
