Lenze EVF9333−xV - Manual (Page 446)

Troubleshooting and fault elimination
Display of operating data, diagnostics
Diagnostics
9
9.1
9.1.2
l
9.1−2 EDSVF9333V EN 6.2−04/2012
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0064 Utilization 0 {1 %} 150 Device utilisation I×t
l Read only
l Device utilisation during the
last 180 s of operating time
l C0064 > 100 % releases
warning OC5
l C0064 > 140 % limits the
output current of the controller
to 67 % of the maximum
current in C0022
^
8.2−25
^
8.2−48
C0150 Status word Bit00 — Bit08 Status code Read only
Decimal status word for
networking via automation
interface (AIF)
l Binary interpretation indicates
the bit states
See System
Manual
(extension)
Bit01 IMP Bit09 Status code
Bit02 — Bit10 Status code
Bit03 — Bit11 Status code
Bit04 — Bit12 Warning
Bit05 — Bit13 Message
Bit06 n = 0 Bit14 —
Bit07 CINH Bit15 —
9.1.2 Diagnostics
Display codes for diagnostics
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0093 DRIVE IDENT Controller identification
l Read only
0 invalid Damaged power section
1 none No power section
9321
...
9333 9321VC
...
9333VC Display of the controller used
C0099 S/W version x.y Software version
l Read only
x
y Main version
Subversion
Description
