Technical data
Operation with rated power (normal operation)
Rated data for 400 V mains voltage
3
3.4
3.4.1
l
3.4−1 EDSVF9333V EN 6.2−04/2012
3.4 Operation with rated power (normal operation)
)
Note!
The controllers EVF9324, EVF9326 and EVF9328 EVF9333 may
only be operated with the prescribed mains chokes and mains
filters.
3.4.1 Rated data for 400 V mains voltage
Basis of the data
Voltage Frequency
AC mains connection [V
rate
d
]
3/PE AC 320 V − 0 % ... 440 V + 0 % 45 Hz − 0 % ... 65 Hz + 0 %
DC−mains connection
(alternatively) [U
DC
] DC 450 V − 0 % ... 620 V + 0 % ˘
Output voltage
With mains choke 3 ~ 0 approx. 94 % V
rated
˘
Without mains choke 3 ~ 0 ... U
N
˘
9300 Mains current 1) Typical motor power Output power Power loss
With
Mains choke
Without
Mains choke
ASM
(4−pole)
2/4 kHz 2) 8 kHz 2)
U, V, W U, V, W +U
G
, −U
G
3)
Type I
r
[A] I
r
[A] P
rated
[kW] P
rated
[hp] S
rated
[kVA] S
rated
[kVA] P
DC
[kW] P
loss
[W]
EVF9321−xV 1.5 2.1 0.37 0.5 1.0 1.0 1.9 50
EVF9322−xV 2.5 3.5 0.75 1.0 1.7 1.7 0.7 65
EVF9323−xV 3.9 5.5 1.5 2.0 2.7 2.7 0 100
EVF9324−xV 7.0 ˘ 3.0 4.0 4.8 4.8 2.0 150
EVF9325−xV 12.0 16.8 5.5 7.5 9.0 9.0 0 210
EVF9326−xV 20.5 ˘ 11.0 15.0 16.3 16.3 0 390
EVF9327−xV 29.0 43.5 15.0 20.0 22.2 22.2 10.2 430
EVF9328−xV 42.0 ˘ 22.0 30.0 32.6 32.6 4.0 640
EVF9329−xV 55.0 ˘ 30.0 40.0 41.6 41.6 0 810
EVF9330−xV 80.0 ˘ 45.0 60.0 61.7 61.7 5.1 1100
EVF9331−xV 100 ˘ 55.0 75.0 76.2 76.2 0 1470
EVF9332−xV 135 ˘ 75.0 100 103.9 103.9 28.1 1960
EVF9333−xV 165 ˘ 90.0 125 131.2 124.7 40.6 2400
1) Mains currents at a switching frequency of 8 kHz
2) Switching frequency of the inverter
3) Power supplied by the DC bus when operating with power−adapted motor
