Lenze EVF9333−xV - Manual (Page 159)

Wiring of the standard device
Wiring of the feedback system
Important notes
5
5.10
5.10.1
l
5.10−1 EDSVF9333V EN 6.2−04/2012
5.10 Wiring of the feedback system
5.10.1 Important notes
ƒ An incremental encoder can be connected to input X8 or input X9:
– Incremental encoders with TTL level are connected to X8.
– Incremental encoders with HTL level are connected to X9.
ƒ The incremental encoder signal can be output for slave drives at the
digital frequency output X10.
)
Note!
ƒ We recommend to use Lenze system cables for wiring.
ƒ For self−made cables only use cables with shielded cores
twisted in pairs.
Installation material required from the scope of supply:
Description Use Quantity
Protective cover Protection for unused Sub−D connections 4
