Wiring of the standard device
Standard devices in the power range 15 ... 30 kW
Mains choke/mains filter assignment
5
5.5
5.5.5
l
5.5−7 EDSVF9333V EN 6.2−04/2012
5.5.5 Mains choke/mains filter assignment
Operation with rated power (normal operation)
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9327−xV ELN3−0088H035−001 EZN3A0110H030 25 E82ZN22334B230 10
E82ZZ15334B230 1) 10
E82ZN22334B230 50 EZN3B0110H030U 2) 50
E82ZZ15334B230 1) 50
EVF9328−xV ELN3−0075H045 EZN3A0080H042 25 E82ZN22334B230 10
E82ZN22334B230 50 EZN3B0080H042 50
EVF9329−xV ELN3−0055H055 EZN3A0055H060 25 E82ZN30334B230 10
E82ZN30334B230 50 EZN3B0055H060 50
1) RFI filter
2) Footprint filter
Operation with increased rated power
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9327−xV ELN3−0075H045 EZN3A0080H042 25 E82ZN22334B230 10
E82ZN22334B230 50 EZN3B0080H042 50
EVF9328−xV ELN3−0055H055 EZN3A0055H060 25 E82ZN30334B230 10
E82ZN30334B230 50 EZN3B0055H060 50
EVF9329−xV ˘ EZN3B0055H060N003 50 EZN3B0055H060N003 50
