Lenze EVF9333−xV - Manual (Page 110)

Wiring of the standard device
Standard devices in the power range 0.37 ... 11 kW
Mains choke/mains filter assignment
5
5.4
5.4.5
l
5.4−8 EDSVF9333V EN 6.2−04/2012
5.4.5 Mains choke/mains filter assignment
Operation with rated power (normal operation)
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9321−xV EZN3A2400H002 EZN3A2400H002 5 EZN3B2400H002 50
EVF9322−xV EZN3A1500H003 EZN3A1500H003 5 EZN3B1500H003 50
EVF9323−xV EZN3A0900H004 EZN3A0900H004 5 EZN3B0900H004 50
EVF9324−xV EZN3A0500H007 EZN3A0500H007 5 EZN3B0500H007 50
EVF9325−xV EZN3A0300H013 EZN3A0300H013 5 EZN3B0300H013 50
EVF9326−xV ELN3−0150H024−001 EZN3A0150H024 5 EZN3B0150H024 50
Operation with increased rated power
9300 Mains choke Interference voltage category according to EN 61800−3 and motor cable length
Component Component
Type C2 max. [m] C1 max. [m]
EVF9321−xV EZN3A2400H002 EZN3A2400H002 5 EZN3B2400H002 50
EVF9322−xV EZN3A1500H003 EZN3A1500H003 5 EZN3B1500H003 50
EVF9323−xV EZN3A0750H005 EZN3A0750H005 5 EZN3B0750H005 50
EVF9324−xV EZN3A0400H009 EZN3A0400H009 5 EZN3B0400H009 50
EVF9325−xV EZN3A0300H013 EZN3A0300H013 5 EZN3B0250H015 50
