Structure of the parameter "automation control word":
Bit Name Meaning
0 Switch on Controller states
0 = command 2,6,8 (controller inhibit)
1 = command 3 (not controller inhibit)
1 Disable voltage Controller states
0 = command 7,9,10,12 (controller inhibit)
1 = not command disable voltage
2 Quick stop Controller states
0 = command 7,10,11 (quick-Stop)
1 = not command quick stop
3 Operation enabled Controller states
0 = command 5 (controller inhibit)
1 = command 4 (not controller inhibit)
4 OM-Contr4
2211: PRG-START
2212: not used Operating mode control function 4 depends on the automation
software package.
0 = inactive
1 = active
5 OM-Contr5
2211: PRG-RESET
2212: not used Operating mode control function 5 depends on the automation
software package.
0 = inactive
1 = active
6 OM-Contr6
2211: PRG-STOP
2212: not used Operating mode control function 6 depends on the automation
software package.
0 = inactive
1 = active
7 Malfunction reset Reset of a fault (TRIP). The bit must be changed from 0 to 1.
8 OM-Contr8
2211: not used
2212: not used Operating mode control function 8 depends on the automation
software package.
0 = inactive
1 = active
9 OM-Contr9
2211: not used
2212: not used Operating mode control function 9 depends on the automation
software package.
0 = inactive
1 = active
10 OM-Contr10
2211: not used
2212: not used Operating mode control function 10 depends on the automation
software package.
0 = inactive
1 = active
11 free 1 Mapping to the 28th freely assignable input (L-1381)
0 = do not activate function
1 = activate function
12 free 2 Mapping to the 29th freely assignable input (L-1381)
0 = do not activate function
1 = activate function
13 free 3 Mapping to the 30th freely assignable input (L-1381)
0 = do not activate function
1 = activate function
14 free 4 Mapping to the 31st freely assignable input (L-1381)
0 = do not activate function
1 = activate function
15 free 5 Mapping to the 32nd freely assignable input (L-1381)
0 = do not activate function
1 = activate function
The individual bit-control commands of the control word are not
independent of the other bit positions. The following list shows which bits
you have to assign in which way in order to activate the desired
command.
