71
4.6.2. Process output data (6011
hex
)
Data format: Unsigned16 with 4 elements
Process data are data memories where several individual parameters
are combined to form a new parameter, the process data. These
process data are exchanged as fast as possible and cyclically between
the controller and the master. Process output data are output data of
the master and thus input data of the controller. The process data
have a fixed length of 4 byte and a summary of parameters is
described in the chapter "process data configuration" (page 67).
Factory setting of the process output dataFactory setting of
process output data:
Byte no. Auto-
mation
module Meaning Index
1 Word1/High-Byte
Bit 8 - 15 POW1
2 Word1/Low-Byte
Bit 0 - 7 No
Yes DRIVECOM control word
Automation control word 6040
hex
58C5
hex
3 Word2/High-Byte
Bit 8 - 15 PIW 2
4 Word2/Low-Byte
Bit 0 - 7 No
Yes DRIVECOM nominal speed value
Automation FDI1 6042
hex
5A9B
hex
4.7. Speed/Velocity channel
4.7.1. Pole number (604D
hex
)
The parameter "pole number" exists only for frequency inverters. It
indicates the pole number of asynchronous motors and is used to
convert frequency values to speed values and vice versa. Only even
numbers are possible.
This is shown on Lenze parameter L-C092.
Index Sub-
index Data
str. Data
type Range/Initialization
604D
hex
0 S U8 2 to 254
L-C092
