3.2.3. Additional procedure for FMS / mixed operation
When using the FMS / mixed operation, some parameters must be set
for the controller and the field bus module, which is only possible by
means of the LECOM1 interface.
For the parameter setting of the controllers using the LEMOC2
program, connect the PC (RS232) and the controller (LECOM1; X6) by
means of a PC system cable.
Name Part no. Explanation
PC system cable 5 m 338 094 System cable 5m between PC (9-pole
socket) and controller
PC system cable 10 m 338 095 System cable 10m between PC (9-pole
socket) and controller
Cable type
Cable resistance
Capacitance per unit length
Length − LIYCY 4 x 0.25mm
screened
< 100
Ω/km
< 140nF/km
≤ 15m
Wiring of the system cable
Controller
9-pole SubD socket
Pin no. PC or similar
9-pole socket
Pin no. PC or similar
25-pole socket
Pin no.
2 (RxD) 3 (TxD) 2 (TxD)
3 (TxD) 2 (RxD) 3 (RxD)
5 (GND) 5 (GND) 7 (GND)
Only use metallized SubD housings. Connect the screen to the
housings at both ends.
