5. Lenze parameters
5.1. Lenze code addressing
The access to Lenze parameters is possible. However, the addressing of
the parameter (code number) is shifted and is calculated as follows:
Index = 24575 - LENZE_CODE NO
Index
hex
= 5FFF
hex
- LENZE_CODE NO
hex
Example:
The Lenze parameter L-C001 (operating mode) can be accessed under
the index 24574 (24575 - 1) using PROFIBUS.
5.2. Lenze data types
The possible Lenze parameters with their ranges are listed in the
corresponding operating instructions. The data of the Lenze parameters
are mainly represented in a fixed-point format of dat type Integer 32 with
four digits after the decimal point.
Example1: L-C039 (JOG) = 150.4Hz
Index = 24575 - 39 = 24536
Index 24536 = 1504000
dez
(0016F300
hex
)
Example 2: L-C039 (JOG) = -150.4Hz
Index = 24575 - 39 = 24536
Index 24536 = -1504000
dez
(FFE90D00
hex
)
