39
Station status_2
(1 byte) Diagnosis data of the controller part 2
Bit no. Meaning
-----------------------------------------------------------------------------------
0
Controller requests new parameter setting.
0 = no request
1 = request for new parameter setting, e.g. since the
DRIVECOM parameter setting channel was changed.
1 User data status
0 = Controller is able to supply user data
1 = Controller is not able supply user data, because
e.g. initializing between communication module and
controller is not yet finished.
2 fixed on 1
3 Communication monitoring in the controller
0 = inactive
1 = active
4 not used
5 Controller input data 'frozen' (Sync)
0 = input data not frozen
1 = input data frozen
6 reserved
7 Information, if the controller parameter set is inactive
and the controller was removed from the cyclic user
data transfer
0 = parameter setting active
1 = parameter setting inactive
Station status_3
(1 byte) Diagnosis data of the controller part 3
Bit no. Meaning
-----------------------------------------------------------------------------------
0 - 6
reserved
7 Overflow of diagnosis information
0 = no overflow
1 = overflow
Master_Add
(1 byte) 1 to 126
PROFIBUS station address of the DP master which has set the
controller parameters. If the parameters are not yet set, the
value 255 is returned.
Ident_Number
( 2 byte) 0082
hex
Fixed identification number for Lenze controllers
Ext_Diag_Data_1
(1 byte) Bit no. Meaning
-----------------------------------------------------------------------------------
0 - 5
fixed value 3
6 - 7 fixed value 0
Ext_Diag_Data_2
(2 byte) Controller-related diagnosis information. Fault code according to
DRIVECOM profile parameter 603F
hex
.
