4.7.11.3. Speed deceleration (6049
hex
)
The parameter "speed deceleration" corresponds to the absolute
speed ramp of the deceleration. The slope is entered indirectly via
the parameters "delta_speed" / "delta_time". The parameter is
mapped via the ramp-min function to the Lenze deceleration ramp
(L-C012). If the parameter "delta_time" = 0, the ramp is switched
off.
Index Sub-
index Data
str. Data
type Range/Initialization
6049
hex
1 RS
(21
hex
)
U32 0 to 4294967295
0
Delta speed in rpm
6049 hex 2 RS
(21
hex
)
U16 0 to 65535
0 (Ramp is switched off)
Delta time in seconds
4.7.11.4. Ramp function time (604F
hex
)
The parameter "ramp function time" corresponds to the relative
speed ramp of the acceleration. The ramp function time refers to
the parameter "speed reference value" (index = 604E
hex ).
Slope
Index E
Index F
hex
hex
=
=
=
' ' ( )
' ' ( )
Speed reference
Acceleration time
604
604
The parameter is mapped via the ramp-min function to the Lenze
acceleration ramp (L-C012). With ramp function time = 0, the ramp
is switched off.
Index Sub-
index Data
str. Data
type Range/Initialization
604F
hex
0 S U32 0 to 495000 (max L-C012 / 2)
L-C012 / 2
Delta time in milliseconds
4.7.11.5. Slow down time (6050
hex
)
The parameter "slow down function time" corresponds to the
relative speed ramp of the deceleration. The ramp function time
refers to the parameter "speed reference value" (index = 604E
hex ).
Slope
Index E
Index
hex
hex
=
=
=
' ' ( )
' ' ( )
Speed reference
Deceleration time
604
6050
The parameter is mapped via the ramp-min function to the Lenze
deceleration ramp (L-C013). With slow down time = 0, the ramp is
switched off.
Index Sub-
index Dat.
Str. Dat.
Typ Range/Initialization
6050
hex
0 S U32 0 to 495000 (max L-C012 / 2)
L-C013 / 2
Delta time in milliseconds
