2. 2130IB code table
In the following, parameters of the 2130IB module are listed which you
can set via the LECOM1 interface (LECOM-A/B).
The parameters listed in the code table are automatically and
permanently saved.
Explanations:
Code: Lenze code number of the parameter. Preceeding
zeros may be omitted.
Name: Name of the parameter
Parameter: Content or meaning of the parameter values.
Parameters printed in bold show the factory setting.
Code
L-C Name Parameter
(Factory setting is printed in bold) Your
settings
1810 Software
identification 33S2130I_xy000
Software identification of the 2130IB module
x = Software main version
y = Software subversion −
1900 PROFIBUS
operating
mode -0- DP operation. Only PROFIBUS-DP
-1- Mixed operation. PROFIBUS-FMS and
PROFIBUS-DP services are possible at the
same time
The operating mode defines the masters which are
able to communicate with the controller. In operating
mode 0 only pure DP masters can be used, and in
operating mode 1 the controller can communicate with
DP or FMS masters.
Data transmission in operating mode 0 is much more
efficient than in operating mode 1.
When changing the operating mode, codes L-C1903
and L-C1904 are also loaded with the corresponding
factory settings.
1901 Station
address 126 1 to 126
Number for precise addressing of the drive in the
PROFIBUS network. This number must only be
assigned once in the bus system.
1902 Baud rate -2- 93.75 kBaud
-3- 187.5 kBaud
-4- 500.0 kBaud
-6- 1500.0 kBaud
In the bus system, all participants must have the same
baud rate. In the operating mode DP operation
(L-C1900 = 0) and automatic baud rate recognition
(L-C1903 = 1), this code number has no meaning.
1903 Baud rate
recognition -0- inactive (L-C1900 = 0)
-1- active (L-C1900 = 1)
Automatic baud rate recognition is only possible in DP
operation; i.e. the drive is set automatically to the baud
rate of the master.
