73
4.7.5. Speed reference variable (6043
hex
)
The parameter "speed reference variable" corresponds to the
output of the ramp function generator (set-value integrator) in rpm.
The reference variable is multiplied by the inverse of the face value
factor and is mapped to L-C381.
Index Sub-
index Data
str. Data
type Range/Initialization
6043
hex
0 S I16 -32768 to 32767
L-C381
4.7.6. Actual speed (6044
hex
)
The parameter "actual speed" corresponds to the actual speed in
rpm. The actual value is multiplied by the inverse of the face value
factors and is mapped to L-C382.
Index Sub-
index Data
str. Data
type Range/Initialization
6044
hex
0 S I16 -32768 to 32767
L-C382
Actual speed in rpm
4.7.7. Nominal percentage (6052
hex
)
The parameter "nominal percentage" corresponds to the nominal
speed in per cent. This parameter is scaled to the speed reference
(100% = 16383). The set-value is multiplied by the face value factor
and is mapped to L-C380. Changing the "nominal percentage" also
changes the parameter "nominal speed". When reading, the
nominal speed is returned, limited to 200%.
Index Sub-
index Data
str. Data
type Range/Initialization
6052
hex
0 S I16 -32768 to 32767
L-C380
Nominal speed in per cent (100% = 16383)
4.7.8. Percentage reference variable (6053
hex
)
The parameter "percentage reference variable" corresponds to the
speed reference variable (see speed reference variable) in per
cent. It is scaled to the speed reference (100% = 16383). The
reference is multiplied by the inverse of the face value factor and is
mapped to L-C381.
Index Sub-
index Data
str. Data
type Range/Initialization
6053
hex
0 S I16 -32768 to 32767
L-C381
Speed reference variable in per cent
(100% = 16383)
