Several control commands can be given at the same time. Please
note that a bit change of bit0 is necessary to change from the
status "SWITCH ON DISABLED". This function is necessary to
avoid an unintended starting of the drive during switch on.
Control commands Bits of the control word
Bit 16 8 7 0
4 Disable ramp
function generator
? ? ? ? ? − − − − − − 0 1 1 1 1
5 Stop ramp function
generator
? ? ? ? ? − − − − − 0 1 1 1 1 1
6 Ramp function
generator zero
? ? ? ? ? − − − − 0 1 1 1 1 1 1
11 free 1 ? ? ? ? 1 − − − − 1 1 1 1 1 1 1
12 free 2 ? ? ? 1 ? − − − − 1 1 1 1 1 1 1
13 free 3 ? ? 1 ? ? − − − − 1 1 1 1 1 1 1
14 free 4 ? 1 ? ? ? − − − − 1 1 1 1 1 1 1
15 free 5 1 ? ? ? ? − − − − 1 1 1 1 1 1 1
free 5
free 4
free 3
free 2
free 1
reserved
reserved
reserved
Reset malfunction
Ramp function
generator zero
Stop ramp function
generator
Disable ramp
function generator
Operation enabled
Quick stop
Disable voltage
Switch on
Explanation
0
Bit state is 0
1 Bit state is 1
− Bit state is not defined and has no effect
? Since function can be freely assigned, a statement about
interdependance is not possible.
