1. Commissioning
1.1. Code numbers / Index
The parameters of the controller are addressed by means of numbers.
These numbers are called "index" according to the PROFIBUS system.
Lenze designates them as code numbers .
All Lenze code numbers begin with 0. They are in an index range from
22576 (5830
hex
) to 24575 (5FFF
hex
). You can recognize Lenze code
numbers by the preceeding letters "L-C" (e.g.: L-C000 for Lenze code
number 000).
The conversion for the address method between code number and index
is given on page 67.
1.2. How to install the PROFIBUS software
The attached "Lenze PROFIBUS diskette" contains
important data and programs about parameter setting
and control of the controller using PROFIBUS.
The diskette (3 ½", DOS format, 1.44 MByte) contains
the following files:
Diskette 3 1/2", DOS format 1.44 MByte including:
INSTALL.EXE Installation program for the following
software
L_AR0082.GSD Controller master data file according to
DIN E 19245 part 3 (PROFIBUS-DP)
LE0082TD.200 Controller master data file for
Simatic-S5 COM-ET200/ IM-308B
(SINEC-L2-DP)
2130@@ST.S5D Example program for Simatic-S5
LEMOC2 PC program for parameter setting of the
drive as of version V2.2
To install the software, insert the diskette into the disk
drive. Enter:
a:\install or b:\install
Further information about the installation is provided by
the "install program".
