Setting using the LEMOC2 PC program
1.
Change to your LEMOC2 directory (...\LM2\BIN) and
start LEMOC2 by entering LM2.
2.
Load the file "2130_xxx.PDB"
(x = serial number)
in the menu "file / controller description".
3.
Load a parameter which contains the corresponding factory setting
in the menu "file / load parameter set".
The following parameter sets are available:
2130_FMS.VAR
Parameter set for PROFIBUS-FMS or
mixed operation
2130_DP.VAR
Parameter set for PROFIBUS-DP
4.
Connect your PC to the controller and switch LEMOC2 on-line.
For this, use the option "setting / general settings".
5.
Inhibit controller (press STP key or F9 key or use controller inhibit
terminal 28).
6.
The 2130IB module can now be activated in the menu
"main menu / drive system"
Set parameter L-C370 (C0370-000) to -1- and transmit the
value to the controller.
6a.
Only required for automation module:
Set parameter L-C1120 (C1120-000) to -3- and
transmit the value to the controller.
Note:
When L-C370 or L-C1120 are modified, the internal interfaces between
the modules are re-initialized. This may result in a delay or refusal of
other services for the time of initialization (max. 30 s). If this is the case,
repeat the service.
7.
Set the operating mode with parameter L-C001
(C0001-000), according to the keypad setting, item 5, and transmit
the value to the controller.
8.
Save the setting in the controller by setting parameter L-C003 to
-1- and by transmitting the value to the controller.
8a.
Only required for automation module:
Save the setting in the controller by setting parameter L-C1003 to
-1- and transmitting the value to the controller.
9.
Enable the controller (press SH + STP keys or F8 key, depending
on item 5). It may be necessary to undo other controller inhibit
sources (terminal 28, TRIP, L-C40).
10. Further information about LEMOC2 and possible error messages
can be obtained from the LEMOC2 help function
(key 1 or "help" menu).
Note:
If you activate the function "Load factory setting" at the controller, the
settings described under 1 to 7 are deleted.
