1.2.3. Selection of the PROFIBUS operating mode
Select the desired PROFIBUS operating mode using the following
table.
PROFIBUS operating mode for the
controllers (parameter L-C1900)
Criteria DP operation
(factory setting) Mixed operation
PROFIBUS-DP master available yes yes (DP)
PROFIBUS-FMS master available no yes (FMS)
Several control masters necessary no yes (FMS)
Control of the controller yes yes (FMS/DP)
Parameter setting of the controller yes yes (FMS/DP)
DRIVECOM profile 21 yes yes (FMS/DP)
Baud rate up to 1.5MBaud yes yes (FMS/DP)
Automatic baud rate recognition yes no
Data transmission time / cycle time small medium
1.2.4. Compatibility with Siemens SINEC-L2
Siemens designates the PROFIBUS communication as SINEC-L2 .
There are a number of variants; their compatibilty with the module
2130IB is listed in the following.
Siemens SINEC-L2 variant Comp. w.
2130IB Explanations
SINEC-L2-FMS Yes FMS = "Fieldbus Message Specification"
Implementation acc. to PROFIBUS standard
DIN 19245 part1 and part 2
SINEC-L2-DP (standard) Yes DP = Decentral peripherial units
Implementation acc. to PROFIBUS standard
DIN 19245 part1 and part 3
(COM ET 200 as of version V4.0)
SINEC-L2-DP (Siemens) No DP = Decentral peripherial units.
Older Siemens-specific DP implementations
which are not compatible with the DP
standard
(COM-ET200 up to version V3.x).
SINEC-L2-STF or
SINEC L2-TF No STF = "Siemens Technologische Funktio-
onen" (Siemens technological functions).
Siemens-specific
Layer7 implementation
SINEC-L2-Layer2 No Siemens-specific communication of a direct
Layer2 access
SINEC-L2-FO Yes Optical fibre cable connection using plastic
OFC / HP duplex
Lenze module variant 2130IB.V002.
