L
48
3.2.2. Communication services
The following FMS communication services are supported by Lenze
controllers:
• Initiate
Make connection from master to controller.
• Abort
Abort connection
• Status
Read status of the controller
• Get-OV
Read object dictionary
• Identify
Identification of the controller
• Read
Reading of parameters
• Write
Writing of parameters
All transmission parameters can be obtained from the host descriptions.
The next chapter contains a list of parameter contents which are returned
by the Lenze controllers.
3.2.2.1. Entries in the communication reference list
You must enter the communication reference list entries yourself.
The following entries in a communication reference list can be set up for
the 2130IB:
Communication reference 1 2
Connection type Master-Slave acyclic Master-Slave acyclic
Connection attribute Defined Defined
Remote LSAP 1 2
R/S Address 0 0
Max-PDU Sending-High-Prio 0 0
Max-PDU Sending-Low-Prio 16 150
Max-PDU Receiving-High-Prio 0 0
Max-PDU Receiving-Low-Prio 16 150
Supported Services Request 00 00 00
hex
80 30 00
hex
Supported Services Response 00 10 00
hex
00 00 00
hex
Max. SCC 1 1
Max. RCC 0 0
Max. SAC 0 0
Max. RAC 0 0
CCI 0 0
