13
2. Technical data
2.1. General data
Communication media RS485 (2130IB.V001)
OFC (SINEC-L2FO) (2130IB.V002)
Communication profile PROFIBUS-FMS (DIN 19245 p1+p2)
PROFIBUS-DP (DIN 19245 p1+p3)
PROFIBUS participant Slave
Drive profile DRIVECOM 21
Baud rate [kBit/s] 93.75, 187.5, 500, 1500
Permissible pollution Degree of pollution 2 according to
VDE 110 part 2
Permissible humidity 80% relative humidity no condensation
Surge strength to the bus system 250V AC (2130IB.V001)
infinite (2130IB.V002)
Ambient temperature 0...45
°C
2.2. Protocol specific data
2.2.1. PROFIBUS-DP
Max. number of controllers 31 (without repeater)
122 (with repeater)
Supported services Data_Exchange, RD_inp, RD_outp,
Slave_Diag, Set_Prm, Chk_Cfg, Get_Cfg,
Global_Control, Set_Slave_add
Functions available as options Sync, Clear_Data
Maximum PDU length 32 Byte
User data length 12 Byte with DP parameter setting channel
4 Byte w/o DP parameter setting channel
Lenze PNO identification number 0082 hex
Controller master data file for
DIN E 19245 part3
Simatic-S5 COM-ET200/IM 308-B
L_AR0082.GSD
LE0082TD.200
DP parameter setting data 10100000
bin
Configuration data
with DP parameter setting channel
without DP parameter setting channel
B7
hex
(183
dez
),A3
hex
(163
dez
),
93
hex
(147
dez
)
A3 hex (163 dez ),93 hex (147 dez )
2.2.2. PROFIBUS-FMS
Max. number of controllers 31 (without repeater)
126 (with repeater)
Supported services Initiate, Abort, Identify, Status, Get-OV-long,
Read, Write
Maximum PDU length 150 Byte
Communication relations Reference 1: Default Management
Reference 2: MSAC
