DFX-8
Ultrasonic Thickness Gauge
79
The user can also access and adjust the gain from the tabbed menus. However, this
method is more tedious than making the adjustments using the right button wheel
approach. The procedure using the tabbed menus is outlined below:
Adjusting the Gain using the Tabbed Menus
1) Press the MENU key once to activate the menu items tab. Press the
MENU key multiple times to tab right, and the ESC key multiple times to tab
left, until the TUNE menu is highlighted and displaying the submenu items.
Alternatively, press the LEFT and RIGHT arrow keys multiple times
using the left button wheel.
2) Press the UP and DOWN arrow keys multiple times using the left button
wheel to scroll through the sub menu items until GAIN is highlighted.
3) Press the LEFT and RIGHT arrow keys multiple times using the left
button wheel to scroll the value. When the correct Gain is being displayed,
proceed to step 8.
4) Alternatively, press the ENTER key to display the Digits Edit Box.
