Dakota Ultrasonics DFX-8 plus MANUAL2 - Manual (Page 54)

Dakota Ultrasonics
50
4) Wipe all couplant from the transducer face and proceed to the Probe Zero
section that follows.
In this second example the transducer was not identified and will force the user to
select the transducer type from a predefined list of transducers:
Selecting the Transducer Type
5) Press the OK or ESC keys to display the factory list of transducer types (by
diameter and frequency).
6) Press the UP and DOWN arrow keys on the left button wheel to scroll
through the transducer list until the appropriate type is highlighted.
