20830-01 Rev 03 Page 4-1
4
UNPACKING AND PARTS LIST
Table of Contents
4 UNPACKING AND PARTS LIST ................................................................................. 4-1
4.1 Unpacking ............................................................................................................... 4-1
4.2 Inventory of Parts .................................................................................................... 4-2
4.3 Class I, Division 2 Label .......................................................................................... 4-2
4.4 European Zone 2 Rated Equipment ......................................................................... 4-2
List of Tables
Table 1 Passive Sonar Meter Parts List ............................................................................... 4-2
4.1 Unpacking
The passive sonar meter will typically be packaged in three shipping
containers. One box will contain the sensor band and sensor cover
assemblies, and installation hardware; the second box will contain the
transmitter assembly and installation hardware; and the third box will
contain the sensor to transmitter cable assembly.
Note: The original packing materials should be saved whenever
possible in the event that the system is removed or relocated.
CAUTION
Use care in unpacking and transporting system. Improper
handling may result in damage to system components.
Whenever possible use the original packing materials to transport the
system to the installation site to minimize the likelihood of damage.
WARNING
Static discharge may occur when handling sensor band and
packing material. Remove packing materials when entering
hazardous areas. Only install if area is known to be non-
hazardous. Always keep the sensor band shorting plug (if so
equipped) installed on sensor band connector whenever the
sensor band is not plugged into the sensor cover preamplifier.
