and outer frames. Place the fabric on top of the outer frame
with the right side of the fabric facing up, and then place the
inner frame inside the outer frame to clamp the fabric.

Inner frame

Outer frame

Screw

Loosen

Right side of fabric

Note
Be sure to align the arrow marks on the two frames (

▲

on the

inner frame with

▼

on the outer frame).

5. Place the inner frame on top of the fabric, place the

embroidery sheet inside the inner frame, and then align the
center of the lines on the sheet with the mark on the fabric.

Inner frame

Line

Note
For best results, lay the outer frame on a flat surface and lay the
fabric on top of it before aligning the center of the embroidery
sheet with the mark on the fabric.

3. Tighten the screw just enough to secure the fabric, and then

gently remove the fabric from the frame without loosening
the screw.

Tighten

Note
This stretches the fabric to help reduce pattern distortions while
embroidering.

4. Remove the inner frame.

Embroidery frames are available in four sizes: extra-large, large, medium, and small.

Embroidery area of extra-large frame: 11-53/64" (30 cm) (H)

5-3/64" (13 cm) (W)

Embroidery area of large frame: 7" (18 cm) (H)

5-3/64” (13 cm) (W)

Embroidery area of medium frame: 4" (10 cm) (H)

4" (10 cm) (W)

Embroidery area of small frame: 25/324" (2 cm) (H)

2-23/64" (6 cm) (W) (for embroidering initials)

CAUTION
–

Depending on the size of the pattern and the position of the pattern to be embroidered, it may
not be possible to use the medium and small frames. When using these frames, be sure to
check the pattern layout on the screen (refer to page 98) before starting to embroider. If the
wrong frame is used by mistake, the presser foot may hit the frame, possibly causing injuries.

–

Do not use any embroidery frames other than those shown here, otherwise injuries could occur.

1. Use a chalk pen to mark the center of the embroidering

position on the fabric.

Inserting the fabric in the embroidery frame
