Pulling up the bobbin thread extra spool pin net, Extra spool pin, Pulling up the bobbin thread – Brother PC 6500 User Manual
Page 30
27
Extra spool pin
When embroidering with metallic thread, use the extra spool pin in order to prevent
the thread from twisting as it unrolls from the spool.
Note
When using metallic thread, we recommend using a 90/14 home sewing machine
needle.
1. Insert the extra spool pin onto the end of the bobbin winder shaft.
2. Place the spool felt on the spool pin.
3. Place the spool of thread on the spool pin so that the thread unrolls from the front
of the spool.
4. Thread the upper thread.
1
Insert the extra spool pin onto the end of the bobbin winder shaft.
2
Spool felt
3
Spool of thread
3
1
2
Net
When using special threads that quickly wind off the spool, place a net over the spool before sewing. Be
sure to cut the net to match the size of the spool.
1
Net
2
Spool
3
Spool pin
4
Spool cap
1
2
3
4
4
1
1. Raise the presser foot lever.
2. Remove the bobbin cover, and insert the bobbin into the
shuttle so that the thread unrolls as shown in the illustration.
3. Guide the thread through the groove, and then leave it there
without cutting it.
1
Bobbin
5
4. With the bobbin cover still removed, hold the upper thread,
press the needle position button twice, and then pull up the
bobbin thread.
5. Pull about 2" (5.0 cm) of the bobbin thread out toward the
rear of the machine and reattach the bobbin cover.
Pulling up the bobbin thread
At some times, for example when making gathers, you may want to pull up the bobbin thread.
