7.35 Device Interrupt Mask
7.35 Device Interrupt Mask
Address 0x35
R/W
7
6
5
4
3
2
1
0
M_PDN_DONE M_THMS_TRIP
M_SYNC_
DONE
M_ADC2B_
OVFL
M_ADC2A_
OVFL
M_ADC1B_
OVFL
M_ADC1A_
OVFL
M_MUTE_PIN
Default
1
1
1
1
1
1
1
1
Interrupt mask register bits serve as a mask for the interrupt sources in the interrupt status registers. Interrupts are described in
.
Registers at addresses 0x35 and 0x36 must not be part of a control-port autoincremented read and must be read individually. See
Bits
Name
Description
7
M_PDN_DONE
PDN_DONE mask
0 Unmasked
1 (Default) Masked
6
M_THMS_TRIP
THMS_TRIP mask
0 Unmasked
1 (Default) Masked
5
M_SYNC_DONE SYNC_DONE mask
0 Unmasked
1 (Default) Masked
4:1
M_ADCxy_OVFL DMICx/ADCx_OVFL mask.
0 Unmasked
1 (Default) Masked
0
M_MUTE_PIN
MUTE_PIN mask
0 Unmasked
1 (Default) Masked
7.36 Device Interrupt Status
Address 0x36
R/O
7
6
5
4
3
2
1
0
PDN_DONE
THMS_TRIP
SYNC_DONE
ADC2B_OVFL ADC2A_OVFL ADC1B_OVFL ADC1A_OVFL
MUTE_PIN
Default
x
x
x
x
x
x
x
x
Interrupt status bits are read only and sticky. Interrupts are described in
. Registers at addresses 0x35 and 0x36 must not be part
of a control-port autoincremented read and must be read only individually. See
.
Bits
Name
Description
7
PDN_
DONE
Power down done. Indicates when the device
has powered down and MCLK can be stopped.
0 Not completely powered down
1 Powered down as a result of PDN_ULP having been set
6
THMS_
TRIP
Thermal sensor trip. If thermal sensing is enabled, this bit indicates whether the current junction temperature has exceeded
the safe operating limits. See
0 Junction temperature is within safe operating limits.
1 Junction temperature has exceeded safe operating limits.
5
SYNC_
DONE
Multichip synchronization sequence done. Indicates that the device has received and confirmed the synchronization protocol.
0 SYNC protocol has not been received.
1 SYNC protocol has been received and confirmed.
4:1
ADCxy_
OVFL
Indicates the overrange status in the corresponding signal path. Rising-edge state transitions may cause an interrupt,
depending on the programming of the associated interrupt mask bit.
0 No digital clipping has occurred in the data path of the indicated digital ADC
1 Digital clipping has occurred in the data path of the indicated digital ADC
0
MUTE_
PIN
MUTE pin asserted. Indicates that the MUTE pin has been asserted.
0 MUTE pin not asserted
1 MUTE pin asserted
