4.4 Capture-Path Inputs
4.3.2
Interrupt Handling with the QFN Package
The interrupt pin (INT) is implemented on the QFN package. Interrupt status bits can be individually masked by setting
corresponding bits in the interrupt mask register (see
). The configuration of mask bits determines which
events cause the assertion of INT:
•
When an unmasked interrupt status event is detected, the status bit is set and INT is asserted.
•
When a masked interrupt status event is detected, the interrupt status bit is set, but INT is not affected.
Once INT is asserted, it remains asserted until all status bits that are unmasked and set have been read. If a condition
remains present and the status bit is read, although INT is deasserted, the status bit remains set.
To clear any status bits set due to the initiation of a path or block, all interrupt status bits should be read after reset and
before normal operation begins. Otherwise, unmasking any previously set status bits causes INT to assert.
Figure 4-2. Example of Rising-Edge Sensitive, Sticky, Interrupt Status Bit Behavior (INT Pin in QFN only)
4.4 Capture-Path
Inputs
This section describes the line in and mic inputs.
shows the capture-path signal flow.
Figure 4-3. Capture-Path Signal Flow
Raw signal feeding
status register bit
Status register bit
___
INT pin
Register read
signal
Status read value
0
1
1
0
1
0
Read Source
1
0
P
o
ll cy
cl
e
In
te
rr
u
p
t
se
rv
ic
e
E
x
tr
a
r
e
a
d
f
o
r
pr
e
s
en
t s
ta
te
In
te
rr
u
p
t
se
rv
ic
e
E
x
tr
a
r
e
a
d
f
o
r
pr
e
s
en
t s
ta
te
P
o
ll cy
cl
e
E
x
tr
a
r
e
a
d
f
o
r
pr
e
s
en
t s
ta
te
P
o
ll cy
cl
e
Channel 2B Data Path
Channel 2A Data Path
Channel 1B Data Path
Channel 1A Data Path
PGA
Decimator
PGA
Decimator
Digital Gain
Adjust
HPF
ADC1A
ADC1B
Digital Gain
Adjust
HPF
Noise Gate
To Serial Port
PGA
Decimator
PGA
Decimator
Digital Gain
Adjust
HPF
ADC2A
ADC2B
Digital Gain
Adjust
HPF
Noise Gate
To Serial Port
IN1+/DMIC1_SD
IN2–
IN1–
IN2+
IN3+/DMIC3_SD
IN4–
IN3–
IN4+
