7-7 Copyright 2010 Cirrus Logic, Inc. DS732UM10
Digital Audio Output Port Description
CS4953xx Hardware User’s Manual
6
DAO_MCLK = 512 FS
DAO1_SCLK = DAO_MCLK / 4 = 128 FS
DAO1_LRCLK = DAO1_SCLK / 128 = FS
DAO2_SCLK = DAO_MCLK / 4 = 128 FS
DAO2_LRCLK = DAO2_SCLK / 128 = FS
0x8100003D
0x00017711
0x8100003E
0x00017711
0x8180002C
0xFFFFFF8F
0x8140002C
0x00000040
7
DAO_MCLK = 512 FS
DAO1_SCLK = DAO_MCLK / 2 = 256 FS
DAO1_LRCLK = DAO1_SCLK / 256 = FS
DAO2_SCLK = DAO_MCLK / 2 = 256 FS
DAO2_LRCLK = DAO2_SCLK / 256 = FS
0x8100003D
0x00037701
0x8100003E
0x00037701
0x8180002C
0xFFFFFF8F
0x8140002C
0x00000060
8
DAO_MCLK = 384 FS
DAO1_SCLK = DAO_MCLK / 4 = 96 FS
DAO1_LRCLK = DAO1_SCLK / 96 = FS
DAO2_SCLK = DAO_MCLK / 4 = 96 FS
DAO2_LRCLK = DAO2_SCLK / 96 = FS
0x8100003D
0x00037211
0x8100003E
0x00037211
0x8180002C
0xFFFFFF8F
0x8140002C
0x00000030
9
DAO_MCLK = 384 FS
DAO1_SCLK = DAO_MCLK / 2 = 192 FS
DAO1_LRCLK = DAO1_SCLK / 192 = FS
DAO2_SCLK = DAO_MCLK / 2 = 192 FS
DAO2_LRCLK = DAO2_SCLK / 192 = FS
0x8100003D
0x00077201
0x8100003E
0x00077201
0x8180002C
0xFFFFFF8F
0x8140002C
0x00000050
10
DAO_MCLK = 1024 Fs
DAO1_SCLK = DAO_MCLK/16 = 64 Fs
DAO1_LRCLK = DAOn_SCLK/64 = Fs
DAO2_SCLK = DAO_MCLK/16 = 64 Fs
DAO2_LRCLK = DAOn_SCLK/64 = Fs
0x8100003D
0x00007717
0x8100003E
0x00007717
0x8180002C
0xFFFFFF8F
0x8140002C
0x00000020
11
DAO_MCLK = 64 Fs
DAO1_SCLK = DAO_MCLK/1 = 64 Fs
DAO1_LRCLK = DAOn_SCLK/64 = Fs
DAO2_SCLK = DAO_MCLK/1 = 64 Fs
DAO2_LRCLK = DAOn_SCLK/64 = Fs
0x8100003D
0x00007700
0x8100003E
0x00007700
0x8180002C
0xFFFFFF8F
0x8140002C
0x00000020
Table 7-4. Output DAO_SCLK/LRCLK Configuration (Parameter C) (Continued)
C Value DAO_SCLK Frequency Hex Message
