Cirrus Logic CS4953xx - Manual (Page 114)

D
S
73
2U
M
1
0
C
op
yri
ght 201
0
C
irr
us Log
ic
,
In
c
9
-2
6
Pin A
s
s
ign
me
nts
C
S
495
3xx
H
a
rd
w
a
re
U
s
e
r’s
M
a
n
ual
115 - GPIO4
General Purpose
Input/Output 1. PCP_D4
2. PCP_AD4
1. Parallel Control Port Data
Bus
2. Parallel Control Port
Multiplexed Address and Data
Bus
3.3V
(5V tol)
BiDir IN Y
116 9 GNDIO7 I/O ground 0V PWR
117 - GPIO3
General Purpose
Input/Output 1. PCP_D3
2. PCP_AD3
1. Parallel Control Port Data
Bus
2. Parallel Control Port
Multiplexed Address and Data
Bus
3.3V
(5V tol)
BiDir IN Y
- 10 GPIO3
General Purpose
Input/Output 3.3V
(5V tol)
BiDir IN Y
118 - GPIO2
General Purpose
Input/Output 1. PCP_D2
2. PCP_AD2
1. Parallel Control Port Data
Bus
2. Parallel Control Port
Multiplexed Address and Data
Bus
3.3V
(5V tol)
BiDir IN Y
- 11 GPIO2
General Purpose
Input/Output
1. UART_TXD 1. UART Output
3.3V
(5V tol)
BiDir IN Y
119 12 VDD7
Core power supply
voltage
1.8V PWR
120 - GPIO1
General Purpose
Input/Output 1. PCP_D1
2. PCP_AD1
1. Parallel Control Port Data
Bus
2. Parallel Control Port
Multiplexed Address and Data
Bus
3.3V
(5V tol)
BiDir IN Y
13 GPIO1
General Purpose
Input/Output
1. UART_RXD 1. UART Input
3.3V
(5V tol)
BiDir IN Y
121 - GPIO0
General Purpose
Input/Output 1. PCP_D0
2. PCP_AD0
1. Parallel Control Port Data
Bus
2. Parallel Control Port
Multiplexed Address and Data
Bus
3.3V
(5V tol)
BiDir IN Y
Table 9-10. Pin Assignments (Continued)
LQFP-
144
Pin #
LQFP-
128
Pin #
Function 1
(Default)
Description of Default
Function
Secondary Functions Description of Secondary
Functions
Pwr Type
Reset
State
Pullup
at
Reset
