A. Technical data
130 Festo P.BE-CMMD-AS-HW-EN 1002NH
A.3.6 Power supply [X9]
Characteristics Values
Supply voltage Single-phase/ 95 ... 255 V AC
Suitable for USA/EU mains voltage
Frequency 50 … 60 Hz
Nominal input current 8 ... 10 A
Link voltage 320 V DC
Maximum intermediate circuit voltage 400 V DC with supply voltage 230 V AC
Control section supply voltage 24 V DC ±20 %
Control section nominal current approx. 0.7 A DC
Nominal output current 2 x 4 A
Peak current 2 x 10 A for 2 s or 0.5 s with stopped motor
Intermediate circuit rated power 1200 W
Cooling passive
End stage power loss 60 … 70 W
Own power loss control section 16 W
Table A.15 Technical data: Power data [X9]
Note
To release the holding brake, the voltage tolerances at the holding
brake connection terminals must be maintained.
Characteristics Value internal External values
Braking resistance 115 ≤ 50
Pulse power 1400 W 3200 W
Rated output 30 W 200 W
Response threshold 380 ... 400 V 380 ... 400 V
Hysteresis 10 V 10 V
Table A.16 Technical data: Braking resistor [X9]
A.3.7 Increment generator interface [X10.1/2]
Increment generator interface Values
Operating modes A/B, CW/CCW or CLK/DIR input signals
A,B,N output signals
Angle resolution / number of lines Any number of lines can be set (all whole numbers
between 16 and 2048)
Tracking signals According to RS422 standard
Output impedance 120 Ω
Cut-off frequency at f
Limit
> 500 kHz
Table A.17 Increment generator interface [X10]
