1 cursor 1 reading
2 cursor 2 reading
D P
Power difference between cursor 1 and cursor 2
D t Time difference between cursor 1 and cursor 2
AV Between cursor average if ON
Data hold = MIN (or MAX) :
1 cursor 1 minimum reading, or maximum if MAX mode
2 cursor 2 minimum reading, or maximum if MAX mode
D P Power diff between cursor 1 and cursor 2 minimums
(or maximums if MAX mode)
D t Time difference between cursor 1 and cursor 2 minimums
(or maximums if MAX mode)
Data hold = MIN&MAX:
1 cursor 1 MIN reading
cursor 1 MAX reading
2 cursor 2 MIN reading
cursor 2 MAX reading
D t Time difference between cursor 1 and cursor 2
Power vs. Time Mode
Data hold = NORMAL or AVERAGE:
1 cursor 1 reading
2 cursor 2 reading
D P Power difference between cursor 1 and cursor 2
T1 Time at cursor 1
T2 Time at cursor 2
Data hold = MIN (or MAX) :
1 cursor 1 minimum reading, or maximum if MAX mode
2 cursor 2 minimum reading, or maximum if MAX mode
D P
Power diff between cursor 1 and cursor 2 minimums
(or maximums if MAX mode)
T1 Time at cursor 1
T2 Time at cursor 2
Data hold = MIN&MAX:
1 cursor 1 MIN reading
cursor 1 MAX reading
2 cursor 2 MIN reading
cursor 2 MAX reading
D t Time difference between cursor 1 and cursor 2
Source Sweep mode
Data hold = NORMAL or AVERAGE:
1 cursor 1 reading
4-26 ML2430A OM
SYSTEM MENU OPERATION
