GPIB OPERATION HP 436A EMULATION COMMANDS
Definition Character
STATUS ASCII Decimal
Measured value valid
Watts mode under range
Over range
Under range dBm or dB (Rel) mode
Power Sensor Auto Zero loop enabled; range 1 under range
Power Sensor Auto Zero loop enabled; not range 1 under range
Power Sensor Auto Zero loop enabled; over range P
Q
R
S
T
U
V
80
81
82
83
84
85
86
RANGE
most sensitive 1
2
3
4
least sensitive 5
I
J
K
L
M
73
74
75
76
77
MODE
Watt
dB Rel
dB Ref
dBm A
B
C
D 65
66
67
68
SIGN OF MEASURED VALUE
space (+)
– (minus) SP
–
32
45
MEASURED VALUE DIGITS
0
1
2
3
4
5
6
7
8
9 0
1
2
3
4
5
6
7
8
9 48
49
50
51
52
53
54
55
56
57
Table 6-2 HPIB Output Data Format
