A-8 ML2430A OM
SYSTEM DEFAULTS APPENDIX A
SYSTEM - setup = profile
TRIGGER - setup
source
continuous
sample delay 1 ms
sample gate width 20 ms
source = continuous, manual
trigger arming blanking off
source = internal A, internal B
trigger arming blanking off
trigger type rise
trigger level > –15 dBm
source = external TTL
trigger edge rise
SYSTEM - setup
mode readout
mode = profile
SYSTEM - profile
channel 1
data hold representation normal
data collection period 10 ms
display trigger delay 0 ns
mode = power vs. Time
SYSTEM - pwr vs. Time
channel 1
data hold representation normal
data display time 1 min
mode = source sweep
SYSTEM - source sweep
channel 1
data hold representation normal
source sweep mode frequency
mode = frequency
sweep start
10 MHz
sweep stop 20 GHz
mode = power
sweep start
–10 dB
sweep stop +10 dB
mode = profile, power vs time, source sweep
SYSTEM - control
scale top dB value 20 dB
scale bottom dB value –50 dB
readout on
link cursor off
hold off
