ML2430A OM A-7
APPENDIX A SYSTEM DEFAULTS
frequencies 0 Hz
offset values 0 dB
SENSOR - duty cycle
duty cycle state off
duty cycle 100%
CHANNEL - setup
input config chan 1 = A, chan 2 = off
input config ( HP 437B & HP 438A ) chan 1 = A, chan 2 = off
meas units dBm
meas units ( HP 437B ) dBm
meas units ( HP 438A ) watts
display resolution 2 decimal places
tracking min/max display off
CHANNEL - relative off
CHANNEL - limits
high limit 0 dBm
high limit ( HP 437B ) 90 dBm
high limit ( HP 438A ) 0 dBm
low limit 0 dBm
low limit ( HP 437B ) –90 dBm
low limit ( HP 438A ) 0 dBm
high limit enabled off
low limit enabled off
fail indicator hold off
fail beep control off
TRIGGER
SYSTEM - setup = readout or power vs. time
SENSOR - meas mode = default
std trigger mode
SENSOR - meas mode = mod average std trigger mode
SENSOR - meas mode = custom
TRIGGER - setup
source
continuous
sample delay 1 ms
sample gate width 20 ms
source = continuous, manual
trigger arming blanking off
source = internal A, internal B
trigger arming blanking off
trigger type rise
trigger level > –15 dBm
source = external TTL
trigger edge rise
