Syntax: GRPIX
mode NORM
MINMAX
MIN
MAX
AVG
Remarks: Changes the type of graph displayed:
NORM: Profiles the sensor readings vs. time from the triggered point.
MINMAX: Plots both the MIN and MAX values for each point on the graph.
If connect points (GRCP) is ON, a vertical bar is drawn between the min
and max points.
MIN: Same as NORM, but each point is the minimum value that point has
achieved.
MAX: Same as NORM, but each point is the maximum value that point has
achieved.
AVG: This position plotted on the chart for an x-axis time slot is the aver-
age of all the readings during that x-axis time slot period, and is only avail-
able in Power vs. Time mode.
Query: GRPIX?
Returned
String: GRPIX (Mode can be AVG in Power vs. Time mode.)
GRPRD Profile data collection period PROFILE SETUP
Syntax: GRPRD [units]
val: 100 ns to 7 seconds
Remarks: Sets the time the system will collect data for and scale into the profile
graph after a trigger event.
Example: GRPRD 20US sets the data collection period to 20 microseconds.
Query: GRPRD?
Returned
String: GRPRD
GRPTP Graph Pretrigger Percentage PROFILE SETUP
Syntax: GRPTP [units]
val: 0 to 100
units: PCT
ML2430A OM 6-43
GPIB OPERATION ML24XXA NATIVE COMMANDS
