Syntax: MODRED
count: 0 to 10
Remarks: Sets the number of retrys after a failure to connect. The delay between
retrys is set using MODDEL. See Section 5-10 for more information on mo-
dem operation.
Query: MODRED?
Returned
String: MODRED
MODRNG Autodial enable for range error SYSTEM
Syntax: MODRNG
value: TRUE or FALSE
Remarks: When set to TRUE, produces an SRQ and autodials the phone number
(set with MODPH) when a sensor range error occurs. See Section 5-10 for
more information on modem operation.
Query: MODRNG?
Returned
String: MODRNG
MXGDB Output Max Graph Binary Data DATA OUTPUT
Syntax: MXGDB
Remarks: Available in graph modes only. Outputs in binary form the max graph data
to the GPIB in the long integer form of 1024 bits per dB as a definite length
arbitrary block response data. The C programming example 'Binary output
decoding' on page 6-133 shows how to extract the binary data. The re-
sponse form is as follows :
MXGDB <#>
...<\n>
number of ASCII characters that make up the number_of_bytes
value
number of bytes of data contained in rest of the string
four of these values make up the long integer.
For example: FF FF D1 64 = –11932 As it is based on 1024 per dB, divide
by 1024 to get the dB value (–11.652).
MXGD Output Max Graph Data DATA OUTPUT
