AT-S24 Version 2.01 User’s Guide
53
Naming a Switch
This procedure assigns a name to the switch. The name is displayed in all
Omega windows when you manage the switch. This can make it easier
for you to identify the switches in your network when you configure and
monitor them with Omega.
To assign a name to a switch, perform the following procedure:
1. From the Omega Main Menu, select System Configuration.
The System Configuration menu shown in Figure 8 on page 41 is
displayed.
2. Select System name.
The prompt in Figure 18 is displayed.
Figure 18 System Name Prompt
3. Select the System name prompt and enter a unique name of up to 20
characters. Select Enter or press .
The switch name must be unique within the subnet.
If the switch already has a name that you want to delete without
entering a new name, delete the existing name and enter a space
character.
4. Return to the Main Menu.
The new name is displayed at the top of every Omega screen.
